Connector: circular; HIRSCHMANN

Connector: circular; HIRSCHMANN, CM02E14S-2P, CM06EA14S-2S, CM02E14S-5P, CM06EA14S-5S |EN|
Manufacturer
Conform toMIL-C-5015
VG 95342
IP ratingIP67
Operating temperature-40...90°C
Type of connectorcircular
Mountingsoldering
Urated50V
Contact platingsilver plated
Manufacturer seriesCM
Lockingthreaded joint
Symbol No. of pins Connector Kind Mech. mounting Locking Case
CM02E14S-2P 4 socket male flange (4 holes), for panel mounting external thread size 14S
CM06EA14S-2S 4 plug female for cable internal thread size 14S
CM02E14S-5P 5 socket male flange (4 holes), for panel mounting external thread size 14S
CM06EA14S-5S 5 plug female for cable internal thread size 14S
CM02E14S-6P 6 socket male flange (4 holes), for panel mounting external thread size 14S
CM06EA14S-6S 6 plug female for cable internal thread size 14S
CM02E14S-61P 7 (6+1) socket male flange (4 holes), for panel mounting external thread size 14S
CM06EA14S-61S 7 (6+1) plug female for cable internal thread size 14S
CM02E20-7P 8 socket male flange (4 holes), for panel mounting external thread size 20
CM06EA20-7S 8 plug female for cable internal thread size 20
CM02E20-27P 14 socket male flange (4 holes), for panel mounting external thread size 20
CM06EA20-27S 14 plug female for cable internal thread size 20
CM02E20-29P 17 socket male flange (4 holes), for panel mounting external thread size 20
CM06EA20-29S 17 plug female for cable internal thread size 20

Symbol Cond. cross sec. Imax
[mm2] [A]
CM02E14S-2P 1 10
CM06EA14S-2S 1 10
CM02E14S-5P 1 10
CM06EA14S-5S 1 10
CM02E14S-6P 1 10
CM06EA14S-6S 1 10
CM02E14S-61P 1 10
CM06EA14S-61S 1 10
CM02E20-7P 1.5 10
CM06EA20-7S 1.5 10
CM02E20-27P 1.5 10
CM06EA20-27S 1.5 10
CM02E20-29P 1.5 4
CM06EA20-29S 1.5 4
