Graphic LCD modules, ELECTRONIC ASSEMBLY

Graphic LCD modules, ELECTRONIC ASSEMBLY, EADOGS102B-6, EADOGS102N-6, EADOGS102W-6 |EN|
ManufacturerDISPLAY VISIONS
DisplayLCD
Kind of displaygraphical
Interface:
  • 3-wire SPI (EADOGXLxxx-7, EADOGM240x-6)
  • 4-wire SPI (EADOGS102x-6, EADOGXLxxx-7, EADOGM240x-6)
  • 6800 (EAW320B-8K3LW)
  • 8bit BUS (EADIPxxx, EADOGXL160x-7, EAWxxx, EAP240-6K2LED)
  • I2C (EAEDIPxxx, EADOGXLxxx-7, EADOGM240x-6)
  • RS232 (EAEDIPxxx)
  • SPI (EADOGM1xxx, EADOGL128x-6, EAEDIPxxx)
Symbol Window dimensions Resolution Technology Controller
[mm]
EADOGS102B-6 36x25 102x64 STN Negative UC1701
EADOGS102N-6 36x25 102x64 FSTN Positive UC1701
EADOGS102W-6 36x25 102x64 FSTN Positive UC1701
EADOGM132B-5 51x15 132x32 STN Negative ST7565R
EADOGM132E-5 51x15 132x32 STN Positive ST7565R
EADOGM132L-5 51x15 132x32 STN Positive ST7565R
EADOGM132S-5 51x15 132x32 FSTN Negative ST7565R
EADOGM132W-5 51x15 132x32 FSTN Positive ST7565R
EADOGM128E-6 51x31 128x64 STN Positive ST7565R
EADOGM128L-6 51x31 128x64 STN Positive ST7565R
EADOGM128S-6 51x31 128x64 FSTN Negative ST7565R
EADOGM128W-6 51x31 128x64 FSTN Positive ST7565R
EADIP122-5HNLED 61x19 122x32 STN Positive PT6520
EADIP122-5NLED 61x19 122x32 STN Positive PT6520
EADIP122B-5NLW 61x19 122x32 STN Positive PT6520
EADIP128-6N5LW 61x38 128x64 STN Positive KS0107/108, PT6607/08
EADIP128-6N5LWT 61x38 128x64 STN Positive KS0107/108, PT6607/08
EADIP128J-6N5LW 61x38 128x64 STN Positive KS0107/108, PT6607/08
EADIP128J6N5LWT 61x38 128x64 STN Positive KS0107/108, PT6607/08
EAEDIP128W-6LW 63.5x35 128x64 FSTN Positive -
EAEDIP128W-6LWT 63.5x35 128x64 FSTN Positive -
EADOGL128B-6 64x35.5 128x64 STN Negative ST7565R
EADOGL128E-6 64x35.5 128x64 STN Positive ST7565R
EADOGL128L-6 64x35.5 128x64 STN Positive ST7565R
EADOGL128S-6 64x35.5 128x64 FSTN Negative ST7565R
EADOGL128W-6 64x35.5 128x64 FSTN Positive ST7565R
EAW128-6N2LED 72x40 128x64 STN Positive KS0107/108
EAW128B-6N2LW 72x40 128x64 STN Negative KS0107/108
EADOGXL160B-7 72x45.6 160x104 STN Negative UC1610
EADOGXL160E-7 72x45.6 160x104 STN Positive UC1610
EADOGXL160L-7 72x45.6 160x104 STN Positive UC1610
EADOGXL160S-7 72x45.6 160x104 FSTN Negative UC1610
EADOGXL160W-7 72x45.6 160x104 FSTN Positive UC1610
EADIP180B-5NLW 88x19 180x32 STN Positive PT6520
EADIP180B-5NLWT 88x19 180x32 STN Positive PT6520
EADOGM240B-6 90x23.8 240x64 STN Negative UC1611S
EADOGM240N-6 90x23.8 240x64 FSTN Positive UC1611S
EADOGM240S-6 90x23.8 240x64 FSTN Negative UC1611S
EADOGM240W-6 90x23.8 240x64 FSTN Positive UC1611S
EADOGXL240B-7 90x46.7 240x128 STN Negative UC1611S
EADOGXL240N-7 90x46.7 240x128 FSTN Positive UC1611S
EADOGXL240S-7 90x46.7 240x128 FSTN Negative UC1611S
EADOGXL240W-7 90x46.7 240x128 FSTN Positive UC1611S
EADIP240B-7KLW 96x60.4 240x128 STN Negative T6963C
EAEDIP240B-7LW 96x60.4 240x128 STN Negative -
EAEDIP240B-7LWT 96x60.4 240x128 STN Negative -
EAEDIP240J-7LWT 96x60.4 240x128 FSTN Positive -
EADIP240J-7KLW 96x61 240x128 FSTN Positive T6963C
EADIP240J-7KLWT 96x61 240x128 FSTN Positive T6963C
EAW160-7KHLED 101x82 160x128 STN Negative T6963C
EAW160-7KHLW 101x82 160x128 STN Negative T6963C
EAW240-7KHLEDB 114x64 240x128 STN Positive T6963C
EAW320B-8K3LW 120x105.7 320x240 STN Negative S1D13700
EAEDIP320B-8LW 121x92.6 320x240 STN Negative -
EAW240-6K2HLW 133x39 240x64 STN Negative T6963C
EAP240-6K2LED 134x40.2 - STN Positive T6963C
Symbol Backgr. colour Illumination Backlight colour
EADOGS102B-6 blue - -
EADOGS102N-6 white - -
EADOGS102W-6 white - -
EADOGM132B-5 blue - -
EADOGM132E-5 yellow-green - -
EADOGM132L-5 yellow-green - -
EADOGM132S-5 black - -
EADOGM132W-5 white - -
EADOGM128E-6 yellow-green - -
EADOGM128L-6 yellow-green - -
EADOGM128S-6 black - -
EADOGM128W-6 white - -
EADIP122-5HNLED yellow-green LED yellow-green
EADIP122-5NLED amber LED amber
EADIP122B-5NLW blue LED white
EADIP128-6N5LW blue LED white
EADIP128-6N5LWT blue LED white
EADIP128J-6N5LW white LED white
EADIP128J6N5LWT white LED white
EAEDIP128W-6LW black LED white
EAEDIP128W-6LWT black LED white
EADOGL128B-6 blue - -
EADOGL128E-6 yellow-green - -
EADOGL128L-6 yellow-green - -
EADOGL128S-6 black - -
EADOGL128W-6 white - -
EAW128-6N2LED yellow-green LED yellow-green
EAW128B-6N2LW blue LED white
EADOGXL160B-7 blue - -
EADOGXL160E-7 yellow-green - -
EADOGXL160L-7 yellow-green - -
EADOGXL160S-7 black - -
EADOGXL160W-7 white - -
EADIP180B-5NLW blue LED white
EADIP180B-5NLWT blue LED white
EADOGM240B-6 blue - -
EADOGM240N-6 white - -
EADOGM240S-6 black - -
EADOGM240W-6 white - -
EADOGXL240B-7 blue - -
EADOGXL240N-7 white - -
EADOGXL240S-7 black - -
EADOGXL240W-7 white - -
EADIP240B-7KLW blue LED white
EAEDIP240B-7LW blue LED white
EAEDIP240B-7LWT blue LED white
EAEDIP240J-7LWT black LED white
EADIP240J-7KLW black LED white
EADIP240J-7KLWT black LED white
EAW160-7KHLED blue LED white
EAW160-7KHLW blue LED white
EAW240-7KHLEDB yellow-green LED yellow-green
EAW320B-8K3LW blue LED white
EAEDIP320B-8LW blue LED white
EAW240-6K2HLW blue LED white
EAP240-6K2LED yellow-green LED yellow-green
Symbol Layout No. of pins Contacts ph Dimensions
[mm] [mm]
EADOGS102B-6 1x14 14 2.54 39x38.1
EADOGS102N-6 1x14 14 2.54 39x38.1
EADOGS102W-6 1x14 14 2.54 39x38.1
EADOGM132B-5 1x20 20 2.54 55x17.5
EADOGM132E-5 1x20 20 2.54 55x17.5
EADOGM132L-5 1x20 20 2.54 55x17.5
EADOGM132S-5 1x20 20 2.54 55x17.5
EADOGM132W-5 1x20 20 2.54 55x17.5
EADOGM128E-6 1x20 20 2.54 55x43
EADOGM128L-6 1x20 20 2.54 55x43
EADOGM128S-6 1x20 20 2.54 55x43
EADOGM128W-6 1x20 20 2.54 55x43
EADIP122-5HNLED 2x9 18 2.54 68x26.8
EADIP122-5NLED 2x9 18 2.54 68x26.8
EADIP122B-5NLW 2x9 18 2.54 68x26.8
EADIP128-6N5LW 2x12 24 2.54 75x45.8
EADIP128-6N5LWT 2x12 24 2.54 75x45.8
EADIP128J-6N5LW 2x12 24 2.54 75x45.8
EADIP128J6N5LWT 2x12 24 2.54 75x45.8
EAEDIP128W-6LW 2x16 32 2.54 71.4x54.6
EAEDIP128W-6LWT 2x16 32 2.54 71.4x54.6
EADOGL128B-6 1x20 20 2.54 67.8x47.96
EADOGL128E-6 1x20 20 2.54 67.8x47.96
EADOGL128L-6 1x20 20 2.54 67.8x47.96
EADOGL128S-6 1x20 20 2.54 67.8x47.96
EADOGL128W-6 1x20 20 2.54 67.8x47.96
EAW128-6N2LED 1x20 20 2.54 93x70
EAW128B-6N2LW 1x20 20 2.54 93x70
EADOGXL160B-7 1x16 16 2.54 78x60.96
EADOGXL160E-7 1x16 16 2.54 78x60.96
EADOGXL160L-7 1x16 16 2.54 78x60.96
EADOGXL160S-7 1x16 16 2.54 78x60.96
EADOGXL160W-7 1x16 16 2.54 78x60.96
EADIP180B-5NLW 2x9 18 2.54 102x26.8
EADIP180B-5NLWT 2x9 18 2.54 102x26.8
EADOGM240B-6 1x20 20 2.54 94x38.1
EADOGM240N-6 1x20 20 2.54 94x38.1
EADOGM240S-6 1x20 20 2.54 94x38.1
EADOGM240W-6 1x20 20 2.54 94x38.1
EADOGXL240B-7 1x20 20 2.54 94x63.5
EADOGXL240N-7 1x20 20 2.54 94x63.5
EADOGXL240S-7 1x20 20 2.54 94x63.5
EADOGXL240W-7 1x20 20 2.54 94x63.5
EADIP240B-7KLW 2x20 40 2.54 113x70
EAEDIP240B-7LW 2x20 40 2.54 113x70
EAEDIP240B-7LWT 2x20 40 2.54 113x70
EAEDIP240J-7LWT 2x20 40 2.54 113x70
EADIP240J-7KLW 2x20 40 2.54 113x70
EADIP240J-7KLWT 2x20 40 2.54 113x70
EAW160-7KHLED 1x20 20 - 140x102x19.2
EAW160-7KHLW 1x20 20 - 140x102x19.2
EAW240-7KHLEDB 1x20 20 2.54 144x104
EAW320B-8K3LW 2x10 20 2.54 148x120.4
EAEDIP320B-8LW 2x24 48 2.54 137.8x105.3
EAW240-6K2HLW 2x10 20 2.54 180x65x17
EAP240-6K2LED 1x10 20 2.54 180x61.4
Tape ph:
Features:
  • smart (EAEDIPxxx)
Usup:
Related items:
  • EALED39X41-A (EADOGS102x-6)
  • EALED39X41-GR (EADOGS102x-6)
  • EALED39X41-W (EADOGS102x-6)
  • EALED55X31-A (EADOGM132x-5)
  • EALED55X31-B (EADOGM132x-5)
  • EALED55X31-G (EADOGM132x-5)
  • EALED55X31-R (EADOGM132x-5)
  • EALED55X31-RGB (EADOGM132x-5)
  • EALED55X31-W (EADOGM132x-5)
  • EALED55X46-A (EADOGM128x-6)
  • EALED55X46-B (EADOGM128x-6)
  • EALED55X46-E (EADOGM128x-6)
  • EALED55X46-G (EADOGM128x-6)
  • EALED55X46-R (EADOGM128x-6)
  • EALED55X46-RGB (EADOGM128x-6)
  • EALED55X46-W (EADOGM128x-6)
  • EALED68x51-A (EADOGL128x-6)
  • EALED68x51-B (EADOGL128x-6)
  • EALED68x51-E (EADOGL128x-6)
  • EALED68x51-G (EADOGL128x-6)
  • EALED68x51-R (EADOGL128x-6)
  • EALED68x51-RGB (EADOGL128x-6)
  • EALED68x51-W (EADOGL128x-6)
  • EALED78X64-A (EADOGXL160x-7)
  • EALED78X64-B (EADOGXL160x-7)
  • EALED78X64-E (EADOGXL160x-7)
  • EALED78X64-G (EADOGXL160x-7)
  • EALED78X64-R (EADOGXL160x-7)
  • EALED78X64-RGB (EADOGXL160x-7)
  • EALED78X64-W (EADOGXL160x-7)
  • EALED94X40-A (EADOGM240x-6)
  • EALED94X40-GR (EADOGM240x-6)
  • EALED94X40-W (EADOGM240x-6)
  • EALED94X67-A (EADOGXL240x-7)
  • EALED94X67-GR (EADOGXL240x-7)
  • EALED94X67-W (EADOGXL240x-7)
Supported character set:
  • Cyrillic (EADOGS102x-6)
  • Europe (EADOGS102x-6)
  • Japanese (EADOGS102x-6)
Touchpad:
