GW INSTEK

GW INSTEK, PPX-1005, PPX-1005-GPIB, PPX-10H01, PPX-10H01-GPIB, PPX-2002, PPX-2002-GPIB |EN|
ManufacturerGW INSTEK
Type of laboratory power supplyprogrammable
Symbol Output voltage Output voltage 2 Output voltage 3 Output current Output current 2 Output current 3 Protection Maximum power Dimensions
[V DC] [V DC] [V DC] [A] [A] [A] [W] [mm]
PPX-1005 10 - - 5 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 50 107x124x313
PPX-1005-GPIB 10 - - 5 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 50 107x124x313
PPX-10H01 100 - - 1 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 100 107x124x313
PPX-10H01-GPIB 100 - - 1 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 100 107x124x313
PPX-2002 20 - - 2 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 40 107x124x313
PPX-2002-GPIB 20 - - 2 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 40 107x124x313
PPX-2005 20 - - 5 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 100 107x124x313
PPX-2005-GPIB 20 - - 5 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 100 107x124x313
PPX-3601 36 - - 1 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 36 107x124x313
PPX-3601-GPIB 36 - - 1 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 36 107x124x313
PPX-3603 36 - - 3 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 108 107x124x313
PPX-3603-GPIB 36 - - 3 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 108 107x124x313
PSW-1080L111 30 30 30 36 36 36 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L112 30 30 40 36 36 27 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L114 30 30 80 36 36 13.5 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L115 30 30 160 36 36 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L122 30 40 40 36 27 27 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L124 30 40 80 36 27 13.5 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L125 30 40 160 36 27 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L144 30 80 80 36 13.5 13.5 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L145 30 80 160 36 13.5 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L155 30 160 160 36 7.2 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L222 40 40 40 27 27 27 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L224 40 40 80 27 27 13.5 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L225 40 40 160 27 27 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L244 40 80 80 27 13.5 13.5 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L245 40 80 160 27 13.5 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L255 40 160 160 27 7.2 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L444 80 80 80 13.5 13.5 13.5 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L445 80 80 160 13.5 13.5 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L455 80 160 160 13.5 7.2 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080L555 160 160 160 7.2 7.2 7.2 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080H666 250 250 250 4.5 4.5 4.5 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080H668 250 250 800 4.5 4.5 1.44 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080H688 250 800 800 4.5 1.44 1.44 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW-1080H888 800 800 800 1.44 1.44 1.44 over current OCP, anti-overvoltage OVP 1.08k 214x124x350
PSW160-14.4 0...160 - - 14.4 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 720 350x124x143
PSW160-21.6 0...160 - - 21.6 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 1080 350x124x214
PSW160-7.2 0...160 - - 7.2 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 360 350x124x71
PSW250-13.5 0...250 - - 13.5 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 1080 350x124x214
PSW250-4.5 0...250 - - 4.5 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 360 350x124x71
PSW250-9 0...250 - - 9 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 720 350x124x143
PSW30-108 0...30 - - 108 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 1080 350x124x214
PSW30-36 0...30 - - 36 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 360 350x124x71
PSW30-72 0...30 - - 72 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 720 350x124x143
PSW40-27 0...40 - - 27 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 360 350x124x71
PSW40-54 0...40 - - 54 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 720 350x124x142
PSW40-81 0...40 - - 81 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 1.08k 350x124x214
PSW-720L11 30 30 - 36 36 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L12 30 40 - 36 27 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L14 30 80 - 36 13.5 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L15 30 160 - 36 7.2 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L22 40 40 - 27 27 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L24 40 80 - 27 13.5 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L25 40 160 - 27 7.2 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L44 80 80 - 13.5 13.5 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L45 80 160 - 13.5 7.2 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720L55 160 160 - 7.2 7.2 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720H66 250 250 - 4.5 4.5 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720H68 250 800 - 4.5 1.44 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW-720H88 800 800 - 1.44 1.44 - over current OCP, anti-overvoltage OVP 720 142x124x350
PSW800-1.44 0...800 - - 1.44 - - - 360 350x124x71
PSW800-2.88 0...800 - - 2.88 - - - 720 350x124x143
PSW800-4.32 0...800 - - 4.32 - - - 1080 350x124x214
PSW80-13.5 0...80 - - 13.5 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 360 350x124x71
PSW80-27 0...80 - - 27 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 720 350x124x143
PSW80-40.5 0...80 - - 40.5 - - anti-overload OPP, anti-overvoltage OVP, overheating OTP 1080 350x124x214
Number of channels:
  • 1 (PPX-xxx, PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx, PSW80xxx)
  • 2 (PSW-720xxx)
  • 3 (PSW-1080xxx)
Kind of power supply:
  • switching (PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx, PSW80xxx)
  • single-channel (PPX-xxx, PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx, PSW80xxx)
  • multi-channel (PSW-xxx)
Interface:
  • analog (PPX-xxx, PSW-xxx)
  • Ethernet (PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx, PSW80xxx)
  • GPIB (PPX-xxx-GPIB)
  • LAN
  • RS232 (PPX-xxx)
  • RS485 (PPX-xxx)
  • USB
Usup:
  • 85...265V AC (PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx, PSW80xxx)
  • 100...240V AC (PPX-xxx, PSW-xxx)
Output plug:
  • RJ45 socket (PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx, PSW80xxx)
  • USB A socket (PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx, PSW80xxx)
  • USB B socket (PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx, PSW80xxx)
Features:
  • sweep function for DUT characteristic analysis (PSW-xxx)
  • sequence test function (PPX-xxx)
  • remote sensing function (PPX-xxx)
  • simultaneous voltage and current readout (PSWxxx)
  • possibility to connect to 31 units in series (PPX-xxx)
  • 10 sets memory (PPX-xxx)
  • constant voltage or constant current operation (PSWxxx)
  • adjustable voltage and current slew rates (PPX-xxx)
  • operates with thermocouple types: K (PPX-xxx)
Operating modes:
  • constant voltage (PPX-xxx, PSW-xxx)
  • constant current (PPX-xxx, PSW-xxx)
Mounting:
  • rack (PPX-xxx, PSW-xxx)
Equipment:
  • user's manual (PPX-xxx)
  • mains cable (PPX-xxx)
  • test leads (PPX-xxx)
Additional functions:
  • data logger (PPX-xxx)
Measurement:
  • power (PPX-xxx)
  • DC voltage (PPX-xxx)
  • DC current (PPX-xxx)
  • temperature (external probe required) (PPX-xxx)
Display:
  • LCD TFT 2,4" (PPX-xxx)
  • LED (PSW-1080xxx)
Support:
  • SCPI (PSW-xxx)
Display parameters:
  • 5 digits (PPX-xxx)
Voltage (regulated) ripple and noise:
Operating temperature:
  • 0...40°C (PPX-xxx)
  • 0...50°C (PSW-xxx, PSW160-xxx, PSW250-xxx, PSW30-xxx, PSW40-xx)
Current stabilisation:
Voltage stabilisation:
Software:
  • LabVIEW (PSWxxx)
Related items:
  • GRA-410-E (PSW40-xx)
  • GRA-441-E (PPX-xxx)
  • GRA-441-J (PPX-xxx)
  • GTL-123 (PSW40-xx)
  • GTL-130 (PSW40-xx)
  • GTL-248 (PSW40-xx)
  • GTL-250 (PSW40-xx)
Connectors for the country:
  • Europe (PPX-xxx, PSW-xxx, PSW160-xxx, PSW30-xxx, PSW40-xx, PSW80-xxx)
