Insulated fuseholders
| Body material | thermoplastic |
| Symbol | Fuse accessories | Colour | Flammability rating | Rated volt. | Max. current | Mounting |
|---|---|---|---|---|---|---|
| [V AC] | [A] | |||||
| ZHL15 | fuse holder | yellow | UL94V-1 | 250 | 6.3 | THT |
| ZHL18 | fuse holder | black | UL94V-0 | 250 | 10 | THT |
| ZHL45 | fuse holder | black | UL94V-0 | 250 | 10 | THT |
| ZHL50 | fuse holder | black | UL94V-0 | 250 | 10 | THT |
| ZHL60 | fuse holder | white | UL94V-0 | 250 | 6.3 | THT |
| ZHL75 | fuse holder | green | UL94V-0 | 250 | 6.3 | THT |
| ZHL76A | fuse holder | green | UL94V-0 | 250 | 6.3 | THT |
| ZHL77 | fuse holder | green | UL94V-0 | 250 | 6.3 | THT |
| ZHL78 | fuse holder | green | UL94V-0 | 250 | 6.3 | THT |
| ZHL7X-H | cover | green | UL94V-0 | - | - | - |
| Symbol | Operating temperature | Pitch | Body dimensions | Mounting hole | Contact resist. | Related items | Leads | Fuse accessories application | Lead length |
|---|---|---|---|---|---|---|---|---|---|
| [°C] | [mm] | [mm] | [mm] | [mΩ] | [mm] | ||||
| ZHL15 | -30...85 | 22.6 | 22x13.5x9 | Ø1.5 | 5 | ZHL31H | for PCB, straight | cylindrical fuses | 4.5 |
| ZHL18 | -30...85 | 22.5 | - | Ø1.3 | 5 | ZHL18-H | - | cylindrical fuses | 4.5 |
| ZHL45 | -30...85 | 10 | Ø10x33.1 | Ø1.3 | 5 | - | - | cylindrical fuses | 4 |
| ZHL50 | -30...85 | 10 | Ø10x33.1 | Ø1.3 | 5 | - | - | cylindrical fuses | 5 |
| ZHL60 | -30...85 | 15 | - | Ø1.3 | 5 | - | - | cylindrical fuses | 3.5 |
| ZHL75 | -30...85 | 15 | 24.4x10.5x9.4 | Ø1.5 | 5 | ZHL7X-H | - | cylindrical fuses | 3.5 |
| ZHL76A | -30...85 | 15 | 24.4x10.5x9.4 | Ø1.5 | 5 | ZHL7X-H | - | cylindrical fuses | 3.5 |
| ZHL77 | -30...85 | 22.6 | 24.4x10.5x9.4 | Ø1.5 | 5 | ZHL7X-H | - | cylindrical fuses | 3.5 |
| ZHL78 | -30...85 | 22.6 | 24.4x10.5x9.4 | Ø1.5 | 5 | ZHL7X-H | - | cylindrical fuses | 3.5 |
| ZHL7X-H | -30...85 | - | - | - | - | ZHL30, ZHL75, ZHL76, ZHL76A, ZHL77, ZHL78 | - | - | - |
