Laboratory generator: arbitrary, function; GW INSTEK
| Symbol: (AFG-2012) | |
|---|---|
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | LCD 3,5" |
| Sampling | 20Msps |
| Number of channels | 1 |
| Memory record length | 4kpts/ch |
| Maximum waveform frequency | 12MHz |
| Vertical resolution | 10bit |
| Output parameters | impedance: 50Ω |
| Interface | USB |
| Dimensions | 266x107x293mm |
| Supply voltage | 100...240V AC |
| Symbol: (AFG-2025) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | LCD 3,5" |
| Sampling | 20Msps |
| Number of channels | 1 |
| Memory record length | 4kpts/ch |
| Maximum waveform frequency | 25MHz |
| Vertical resolution | 10bit |
| Output parameters | impedance: 50Ω |
| Interface | USB |
| Dimensions | 266x107x293mm |
| Supply voltage | 100...240V AC |
| Symbol: (AFG-2005) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | LCD 3,5" |
| Sampling | 20Msps |
| Number of channels | 1 |
| Memory record length | 4kpts/ch |
| Maximum waveform frequency | 5MHz |
| Vertical resolution | 10bit |
| Output parameters | impedance: 50Ω |
| Interface | USB |
| Dimensions | 266x107x293mm |
| Supply voltage | 100...240V AC |
| Symbol: (AFG-3021) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD TFT 4,3" |
| Sampling | 250Msps |
| Number of channels | 1 |
| Memory record length | 8Mpts |
| Maximum waveform frequency | 20MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 265x107x374mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-3021GP) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD TFT 4,3" |
| Sampling | 250Msps |
| Number of channels | 1 |
| Memory record length | 8Mpts |
| Maximum waveform frequency | 20MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | GPIB; LAN; USB |
| Dimensions | 265x107x374mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-3031) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD TFT 4,3" |
| Sampling | 250Msps |
| Number of channels | 1 |
| Memory record length | 8Mpts |
| Maximum waveform frequency | 30MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 265x107x374mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-3031GP) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD TFT 4,3" |
| Sampling | 250Msps |
| Number of channels | 1 |
| Memory record length | 8Mpts |
| Maximum waveform frequency | 30MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | GPIB; LAN; USB |
| Dimensions | 265x107x374mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-3022) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD TFT 4,3" |
| Sampling | 250Msps |
| Number of channels | 2 |
| Memory record length | 8Mpts |
| Maximum waveform frequency | 20MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 265x107x374mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-3022GP) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD TFT 4,3" |
| Sampling | 250Msps |
| Number of channels | 2 |
| Memory record length | 8Mpts |
| Maximum waveform frequency | 20MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | GPIB; LAN; USB |
| Dimensions | 265x107x374mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-3032) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD TFT 4,3" |
| Sampling | 250Msps |
| Number of channels | 2 |
| Memory record length | 8Mpts |
| Maximum waveform frequency | 30MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 265x107x374mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-3032GP) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD TFT 4,3" |
| Sampling | 250Msps |
| Number of channels | 2 |
| Memory record length | 8Mpts |
| Maximum waveform frequency | 30MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | GPIB; LAN; USB |
| Dimensions | 265x107x374mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-4125E, AFG-4125AE) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD 8" |
| Sampling | 125Msps |
| Number of channels | 1 |
| Memory record length | 16kpts/ch |
| Maximum waveform frequency | 25MHz |
| Vertical resolution | 14bit |
| Output parameters | impedance: 50Ω |
| Interface | USB |
| Dimensions | 340x177x90mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-4225E) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | colour, LCD 8" |
| Sampling | 125Msps |
| Number of channels | 2 |
| Memory record length | 10Mpts/ch |
| Maximum waveform frequency | 25MHz |
| Vertical resolution | 14bit |
| Output parameters | impedance: 50Ω |
| Interface | USB |
| Dimensions | 340x177x90mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-4235) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | touch screen, colour, LCD 8" |
| Sampling | 500Msps |
| Number of channels | 2 |
| Memory record length | 10Mpts/ch |
| Maximum waveform frequency | 35MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 340x177x90mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-4260) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | touch screen, colour, LCD 8" |
| Sampling | 500Msps |
| Number of channels | 2 |
| Memory record length | 10Mpts/ch |
| Maximum waveform frequency | 60MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 340x177x90mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-4280) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | touch screen, colour, LCD 8" |
| Sampling | 500Msps |
| Number of channels | 2 |
| Memory record length | 10Mpts/ch |
| Maximum waveform frequency | 80MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 340x177x90mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-4210H) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | touch screen, colour, LCD 8" |
| Sampling | 500Msps |
| Number of channels | 2 |
| Memory record length | 10Mpts/ch |
| Maximum waveform frequency | 100MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 340x177x90mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-4225H) | |
| Manufacturer | GW INSTEK |
| Type of laboratory generator | arbitrary, function |
| Display | touch screen, colour, LCD 8" |
| Sampling | 1,25Gsps |
| Number of channels | 2 |
| Memory record length | 10Mpts/ch |
| Maximum waveform frequency | 250MHz |
| Vertical resolution | 16bit |
| Output parameters | impedance: 50Ω |
| Interface | LAN; USB |
| Dimensions | 340x177x90mm |
| Supply voltage | 100...240V AC |
| Modulation | AM, FM, FSK, MSK, PSK, PWM, QAM, SUM |
| Symbol: (AFG-20xx) | |
|---|---|
| Waveforms | arbitrary, rectangular, sinus, noise, triangle |
| Symbol: (AFG-302xxx, AFG-3031GP, AFG-3032, AFG-3032GP) | |
| Waveforms | arbitrary, burst, cardiac, DC, ECG1, ECG2, ECG3, harmonic, impulse, ISO7637-2 TP2B, ISO7637-2 TP3A, ISO7637-2 TP3B, rectangular, sweep, sinus, noise, triangle, ignition |
| Symbol: (AFG-3031) | |
| Waveforms | arbitrary, cardiac, DC, ECG1, ECG2, ECG3, harmonic, impulse, ISO7637-2 TP2B, ISO7637-2 TP3A, ISO7637-2 TP3B, rectangular, sinus, noise, triangle, ignition |
| Symbol: (AFG-4xxx) | |
| Waveforms | arbitrary, harmonic, square, rectangular, sinus, noise, triangle |
| Symbol | AFG-2012 | AFG-2025 | AFG-2005 | AFG-3021 | AFG-3021GP | AFG-3031 | AFG-3031GP | AFG-3022 | AFG-3022GP | AFG-3032 | AFG-3032GP |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Waveform frequency range | |||||||||||
| - 0,1Hz...12MHz (rectangular waveform) | x | ||||||||||
| - 0,1Hz...12MHz (sinus waveform) | x | ||||||||||
| - 0,1Hz...1MHz (triangle waveform) | x | x | x | ||||||||
| - 0,1Hz...25MHz (rectangular waveform) | x | ||||||||||
| - 0,1Hz...25MHz (sinus waveform) | x | ||||||||||
| - 0,1Hz...5MHz (rectangular waveform) | x | ||||||||||
| - 0,1Hz...5MHz (sinus waveform) | x | ||||||||||
| - 1µHz...1MHz (ramp waveform) | x | x | x | x | x | x | x | x | |||
| - 1µHz...1MHz (triangle waveform) | x | x | x | x | x | x | x | x | |||
| - 1µHz...20MHz (pulse waveform) | x | x | x | x | |||||||
| - 1µHz...20MHz (rectangular waveform) | x | x | x | x | |||||||
| - 1µHz...20MHz (sinus waveform) | x | x | x | x | |||||||
| - 1µHz...25MHz (pulse waveform) | x | x | x | x | |||||||
| - 1µHz...30MHz (rectangular waveform) | x | x | x | x | |||||||
| - 1µHz...30MHz (sinus waveform) | x | x | x | x | |||||||
| - 1µHz...40MHz (arbitrary waveform) | x | x |
Features:
- power amplifier function (AFG-4125AE)
- insulated outputs (AFG-3022, AFG-3022GP, AFG-3032, AFG-3032GP)
- possibility to connect 4 units in series or 6 in parallel (AFG-30xxx)
- 10 sets memory (AFG-20xx, AFG-30xxx)
Equipment:
- BNC cable (AFG-30xxx)
- USB cable (AFG-4xxx)
- mains cable (AFG-20xx, AFG-4xxx)
- test leads (AFG-20xx)
Software:
- included (AFG-30xxx)
- LabVIEW (AFG-20xx)
| Symbol | Product description | Connectors for the country |
|---|---|---|
| AFG-2012 | Laboratory generator:arbitrary, function;12MHz;LCD 3,5";Ch:1 | Europe |
| AFG-2025 | Laboratory generator:arbitrary, function;25MHz;LCD 3,5";Ch:1 | Europe |
| AFG-2005 | Laboratory generator:arbitrary, function;5MHz;LCD 3,5";Ch:1 | Europe |
| AFG-3021 | Laboratory generator:arbitrary, function;20MHz;Ch:1;8Mpts | - |
| AFG-3021GP | Laboratory generator:arbitrary, function;20MHz;Ch:1;8Mpts | - |
| AFG-3031 | Laboratory generator:arbitrary, function;30MHz;Ch:1;8Mpts | - |
| AFG-3031GP | Laboratory generator:arbitrary, function;30MHz;Ch:1;8Mpts | - |
| AFG-3022 | Laboratory generator:arbitrary, function;20MHz;Ch:2;8Mpts | - |
| AFG-3022GP | Laboratory generator:arbitrary, function;20MHz;Ch:2;8Mpts | - |
| AFG-3032 | Laboratory generator:arbitrary, function;30MHz;Ch:2;8Mpts | - |
| AFG-3032GP | Laboratory generator:arbitrary, function;30MHz;Ch:2;8Mpts | - |
| AFG-4125E | Laboratory generator:arbitrary, function;25MHz;colour,LCD 8" | - |
| AFG-4125AE | Laboratory generator:arbitrary, function;25MHz;colour,LCD 8" | - |
| AFG-4225E | Laboratory generator:arbitrary, function;25MHz;colour,LCD 8" | - |
| AFG-4235 | Laboratory generator:arbitrary, function;35MHz;Ch:2;AFG-4000 | - |
| AFG-4260 | Laboratory generator:arbitrary, function;60MHz;Ch:2;AFG-4000 | - |
| AFG-4280 | Laboratory generator:arbitrary, function;80MHz;Ch:2;AFG-4000 | - |
| AFG-4210H | Laboratory generator:arbitrary, function;100MHz;Ch:2 | - |
| AFG-4225H | Laboratory generator:arbitrary, function;250MHz;Ch:2 | - |
