Push-in fitting; threaded, angled 90°; SMC
| Manufacturer | SMC |
| Pneumatic accessories | push-in fitting |
| Splice terminal variant | threaded, angled 90° |
| Body material | brass, polypropylene |
| Kind of thread | outside |
| Operating temperature | -5...60°C |
| Operating pressure | -1...10bar |
| Features | 4-fold branch |
| Symbol | Øext. cable | Thread |
|---|---|---|
| [mm] | ||
| KQ2ZD04-01AS | 4 | R 1/8" |
| KQ2ZD04-02AS | 4 | R 1/4" |
| KQ2ZD06-01AS | 6 | R 1/8" |
| KQ2ZD06-02AS | 6 | R 1/4" |
| KQ2ZD06-03AS | 6 | R 3/8" |
| KQ2ZD08-02AS | 8 | R 1/4" |
| KQ2ZD08-03AS | 8 | R 3/8" |
| KQ2ZD08-04AS | 8 | R 1/2" |
| KQ2ZD10-02AS | 10 | R 1/4" |
| KQ2ZD10-03AS | 10 | R 3/8" |
| KQ2ZD10-04AS | 10 | R 1/2" |
| KQ2ZD12-03AS | 12 | R 3/8" |
| KQ2ZD12-04AS | 12 | R 1/2" |
