R&D SOFTWARE SOLUTIONS GSM shields
| Manufacturer | R&D SOFTWARE SOLUTIONS |
| Accessories | expansion board |
| Kit contents | prototype board |
| Symbol | Kind of module | Components | Interface |
|---|---|---|---|
| AGSM2105-BAP | GSM/GPRS | Quectel M95 | UART; USB |
| BGSM2105-BAP | GPS, GSM/GPRS | Quectel M95 | UART; USB |
| DU3G113-SMA-EUR | 3G, GSM/GPRS | Quectel UG95 | UART; USB |
| DU3G113-UFL-EUR | 3G, GSM/GPRS | Quectel UG95 | UART; USB |
| HNANOGSM108-UFL | GSM/GPRS | Quectel M66F | UART; USB |
| LLTE-CAT4-SMA-EUR | 3G, 4G LTE, GPS, GSM/GPRS | Quectel EC21 | UART; USB |
| LLTE-CAT4-UFL-EUR | 3G, 4G LTE, GPS, GSM/GPRS | Quectel EC21 | UART; USB |
| UGSM219-BC95G-SMA | NB-IoT | Quectel BC95G | UART; USB |
| UGSM219-BC95G-UFL | NB-IoT | Quectel BC95G | UART; USB |
| UGSM219-BG95M2-SMA | GNSS, LTE Cat M1, NB-IoT | BG95-M2 | - |
| UGSM219-BG95M2-UFL | GNSS, LTE Cat M1, NB-IoT | BG95-M2 | - |
| UGSM219-BG95M3-SMA | EGPRS, GNSS, LTE Cat M1, NB-IoT | BG95-M3 | - |
| UGSM219-BG95M3-UFL | EGPRS, GNSS, LTE Cat M1, NB-IoT | BG95-M3 | - |
| UGSM219-BG96-SMA | EGPRS, GNSS, LTE Cat M1, NB-IoT | Quectel BG96 | UART; USB |
| UGSM219-BG96-UFL | EGPRS, GNSS, LTE Cat M1, NB-IoT | Quectel BG96 | UART; USB |
| UGSM219-EG91E-SMA | LTE Cat 1 | Quectel EG91E | UART; USB |
| UGSM219-EG91E-UFL | LTE Cat 1 | Quectel EG91E | UART; USB |
| UGSM219-EG95E-SMA | LTE Cat 4 | Quectel EG95E | UART; USB |
| UGSM219-EG95E-UFL | LTE Cat 4 | Quectel EG95E | UART; USB |
| UGSM219-M95FA-SMA | GSM/GPRS/EDGE | Quectel M95FA | UART; USB |
| UGSM219-M95FA-UFL | GSM/GPRS/EDGE | Quectel M95FA | UART; USB |
| UGSM219-UG95E-UFL | 3G | Quectel UG95E | UART; USB |
| UGSM219-UG96-SMA | 3G | Quectel UG96 | UART; USB |
| UGSM219-UG96-UFL | 3G | Quectel UG96 | UART; USB |
| Symbol | Dimensions |
|---|---|
| [mm] | |
| AGSM2105-BAP | 84x53.3 |
| BGSM2105-BAP | 84x53.3 |
| DU3G113-SMA-EUR | 39.88x34.29 |
| DU3G113-UFL-EUR | 39.88x34.29 |
| HNANOGSM108-UFL | 31.75x29.46 |
| LLTE-CAT4-SMA-EUR | 34.29x49.02 |
| LLTE-CAT4-UFL-EUR | 34.29x49.02 |
| UGSM219-BC95G-SMA | 27x45 |
| UGSM219-BC95G-UFL | 27x45 |
| UGSM219-BG95M2-SMA | 27x45 |
| UGSM219-BG95M2-UFL | 27x45 |
| UGSM219-BG95M3-SMA | 27x45 |
| UGSM219-BG95M3-UFL | 27x45 |
| UGSM219-BG96-SMA | 27x45 |
| UGSM219-BG96-UFL | 27x45 |
| UGSM219-EG91E-SMA | 27x45 |
| UGSM219-EG91E-UFL | 27x45 |
| UGSM219-EG95E-SMA | 27x45 |
| UGSM219-EG95E-UFL | 27x45 |
| UGSM219-M95FA-SMA | 27x45 |
| UGSM219-M95FA-UFL | 27x45 |
| UGSM219-UG95E-UFL | 27x45 |
| UGSM219-UG96-SMA | 27x45 |
| UGSM219-UG96-UFL | 27x45 |
Application:
- IoT (HNANOGSM108-UFL, LLTE-CAT4-SMA-EUR, LLTE-CAT4-UFL-EUR, UGSM219-xxx)
- M2M (AGSM2105-BAP, BGSM2105-BAP, DU3G113-SMA-EUR, DU3G113-UFL-EUR)
Part status:
- Not recommended for new designs (UGSM219-UG9xxx)
Bluetooth version:
- 3.0 (BGSM2105-BAP)
Application - series/manufacturer:
- Arduino (UGSM219-BG9xxx, UGSM219-EG9xxx, UGSM219-M95FA-SMA, UGSM219-M95FA-UFL, UGSM219-UG9xxx)
- BeagleBone (UGSM219-BG9xxx, UGSM219-EG9xxx, UGSM219-M95FA-SMA, UGSM219-M95FA-UFL, UGSM219-UG9xxx)
- Raspberry Pi (UGSM219-BG9xxx, UGSM219-EG9xxx, UGSM219-M95FA-SMA, UGSM219-M95FA-UFL, UGSM219-UG9xxx)
Connection:
- Jack 3,5mm x2 (AGSM2105-BAP, BGSM2105-BAP)
- pin strips (AGSM2105-BAP, BGSM2105-BAP, DU3G113-SMA-EUR, DU3G113-UFL-EUR, HNANOGSM108-UFL, LLTE-CAT4-SMA-EUR, LLTE-CAT4-UFL-EUR)
- microSD (AGSM2105-BAP, BGSM2105-BAP)
- SIM (DU3G113-SMA-EUR, DU3G113-UFL-EUR, HNANOGSM108-UFL, LLTE-CAT4-SMA-EUR, LLTE-CAT4-UFL-EUR, UGSM219-BC95G-SMA, UGSM219-BC95G-UFL, UGSM219-BG96-SMA, UGSM219-BG96-UFL, UGSM219-EG9xxx, UGSM219-M95FA-SMA, UGSM219-M95FA-UFL, UGSM219-UG9xxx)
- SIM x2 (AGSM2105-BAP, BGSM2105-BAP)
- SMA (DU3G113-SMA-EUR, LLTE-CAT4-SMA-EUR)
- U.FL (AGSM2105-BAP, BGSM2105-BAP, DU3G113-UFL-EUR, LLTE-CAT4-SMA-EUR, UGSM219-BC95G-UFL, UGSM219-BG96-UFL, UGSM219-EG91E-UFL, UGSM219-EG95E-UFL, UGSM219-M95FA-UFL, UGSM219-UG95E-UFL, UGSM219-UG96-UFL)
- U.FL x2 (HNANOGSM108-UFL, LLTE-CAT4-UFL-EUR)
- USB B micro (AGSM2105-BAP, BGSM2105-BAP, DU3G113-SMA-EUR, DU3G113-UFL-EUR, HNANOGSM108-UFL, LLTE-CAT4-SMA-EUR, LLTE-CAT4-UFL-EUR)
- USB B mini (UGSM219-BC95G-SMA, UGSM219-BC95G-UFL, UGSM219-BG96-SMA, UGSM219-BG96-UFL, UGSM219-EG9xxx, UGSM219-M95FA-SMA, UGSM219-M95FA-UFL, UGSM219-UG9xxx)
