Relay: electromagnetic; PCB; miniature; TE Connectivity
| Manufacturer | TE Connectivity |
| Type of relay | electromagnetic |
| Variant | miniature |
| Mounting | PCB |
| Switched voltage | max. 440V AC |
| Switched voltage | max. 300V DC |
| Switched power | 4kVA |
| Operate time | 8ms |
| Release time | 2ms |
| Coil power consumption | 500mW |
| Mechanical durability | 30000000 cycles |
| Body dimensions | 29x12.6x25.5mm |
| Operating temperature | -40...70°C |
| Dimensions | Fig. 1-1. |
| Symbol | Contacts layout | Ucoil | Rcoil | Icoil | Icontacts max | AC load rating @R* | DC load rating @R* | Term. pitch |
|---|---|---|---|---|---|---|---|---|
| [V DC] | [Ω] | [mA] | [A] | [mm] | ||||
| RP411024 | SPDT | 24 | 1100 | 21.8 | 8 | 8A / 250V AC | 8A / 24V DC | 5 |
| RP412012 | SPDT | 12 | 270 | 44.4 | 8 | 8A / 250V AC | 8A / 24V DC | 3.5 |
| RP421012 | DPDT | 12 | 270 | 44.4 | 8 | 8A / 250V AC | 8A / 24V DC | 5 |
| RP421024 | DPDT | 24 | 1100 | 21.8 | 8 | 8A / 250V AC | 8A / 24V DC | 5 |
| RP420110 | DPDT | 110 | 23100 | 4.8 | 8 | 8A / 250V AC | 8A / 24V DC | 5 |
| RP821012 | DPDT | 12 | 270 | 41.7 | 8 | 8A / 250V AC | 8A / 24V DC | 5 |
| RP821024 | DPDT | 24 | 270 | 21.8 | 8 | 8A / 250V AC | 8A / 24V DC | 5 |
* at resistive load
Output configuration:
